| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | EVERSUN |
| إصدار الشهادات: | ISO,CE |
| رقم الموديل: | كيو في سي |
| الحد الأدنى لكمية: | 1 مجموعة |
| الأسعار: | قابل للتفاوض |
| تفاصيل التغليف: | حالات خشبية التصدير القياسية |
| وقت التسليم: | في غضون 7-15 يوم عمل |
| شروط الدفع: | خطاب الاعتماد، D/A، D/P، T/T، موني جرام، ويسترن يونيون |
| القدرة على العرض: | 5000 مجموعة / سنة |
| استهلاك الطاقة: | استهلاك منخفض | تخصيص المعالجة: | نعم |
|---|---|---|---|
| طريقة التحميل: | رافعة | الكلمة الرئيسية: | محطة الإغراق |
| عملية: | يدوي أو أوتوماتيكي | نوع الشحن: | عن طريق الشحن/الهواء الخ. |
| مستوى الضوضاء: | قليل | التحكم PLC: | يمكن اختيارها |
| متطلبات الطاقة: | 460 فولت، 3 فاز | نوع العملية: | صندوق التحكم / خزانة التحكم / PLC |
| رفع الوزن: | 2 طن | الاستخدام: | تفريغ كيس بالجملة |
| صيانة: | قليل | المواد التطبيقية: | مسحوق / رقائق / جزيئات الخ. |
| البعد: | حسب الطلب |
Product description
The sealed ton bag feeding station is a fully automatic bag-opening and unloading equipment specifically designed for ton bags containing materials. It adopts a fully enclosed structure and integrates material lifting, dust-free bag opening, and efficient dust removal systems, completely solving the problems of dust pollution and high labor intensity caused by traditional manual bag opening. This equipment complies with environmental protection and GMP standards, has a compact structure and customizable materials, and is widely used in the chemical and food industries. It is an ideal choice for achieving automated and clean feeding of powder and granular materials.
Working principle
After the ton bags are lifted and positioned, their discharge ports are introduced into a sealed chamber and sealed tightly. Subsequently, the bag openings are loosened, and the materials fall into the lower hopper under the force of gravity. During this process, the built-in dust removal system operates simultaneously to maintain negative pressure inside the chamber to prevent dust from spilling out. For materials with poor fluidity, the equipment will activate vibration or tapping devices to assist in discharging, preventing bridging. Finally, the materials are automatically sent to the next process through the bottom-connected conveying equipment, completing a dust-free and efficient unloading operation.
Features & Benefits
Main features:
1. Completely sealed structure: Prevents dust from escaping at the source.
2. Modular design: Compact structure, easy to install and maintain, flexible configuration.
3. Function integration: Integrates suspension, disintegration, dust removal, and feeding.
4. Safe and reliable: Equipped with protection and explosion-proof devices to ensure safety.
5. Simple operation: Convenient bag hanging, quick bag replacement, reduces labor intensity.
| Bag size application | 1000x1000x1600 mm |
| Power Source | AC 380 v ± 5%50 Hz |
| Air source pressure | ≥ 0.6MPa |
| Air consumption | ≤ 0.6 m ³/min |
| wind volume for dust-removal | 800-2500m3/h |
| Environment humidity | -100C-400C |
| Cutting capacity | 10-20 bags/h (manual) |
Detail display
Product Shows
Application
The bulk bag unloading machine is mainly used in fields such as plastics, rubber, food, medicine, and chemicals for unpacking and discharging bags of dry powders and granular materials, such as plastic resins and food additives.
